🔷 2 Pair Telephone Cable – Coil of 90 Meters
Shielded 22 AWG Solid Copper Communication Cable
Part Type: 2 Pair | Foil Shielded | 22 AWG | PVC Jacket | 90M Coil
📘 Product Overview
The 2 Pair Shielded Telephone Cable is specifically designed for reliable voice, signal, and low-frequency data transmission. With solid bare copper conductors, aluminium foil shielding, and a tinned copper drain wire, this cable ensures minimal crosstalk and excellent noise immunity—ideal for residential or commercial voice wiring, intercoms, and security systems.
Its compact design and durable grey PVC jacket with nylon rip cord make installation quick, safe, and efficient. Supplied in a 90-meter coil, this is a practical choice for small to medium-sized installations.
2 Pair Shielded Telephone Cable ek khas tor par design ki gayi cable hai jo voice, signal, aur low-frequency data transmission ke liye reliable performance deti hai. Is cable mein solid bare copper conductors, aluminium foil shielding, aur tinned copper drain wire shamil hain jo crosstalk ko kam karte hain aur noise se behtareen tahaffuz faraham karte hain. Yeh cable residential ya commercial voice wiring, intercoms, aur security systems ke liye ideal hai.
Is cable ka compact design aur mazboot grey PVC jacket usay durable banata hai, jabke nylon rip cord se installation asaan aur mehfooz ho jati hai. 90-meter coil mein dastiyab yeh cable chhoti aur darmiyani installations ke liye ek practical choice hai.
✅ Key Features
- Solid Bare Copper Conductors – 22 AWG (0.6 mm)
- PVC Insulated Twisted Pairs
- Spiral Aluminium Foil Shield – Reduces electromagnetic interference
- Tinned Copper Drain Wire – 24 AWG (0.4 mm)
- Grey PVC Jacket with Rip Cord – Easy to strip and terminate
- All Pairs Can Be Used Simultaneously
- No Cross Talk
- Mylar Protection
- Supplied in 90-Meter Coils
📊 Technical Specifications
Attribute | Specification |
Number of Pairs | 2 (4 Conductors) |
Conductor Material | Solid Bare Copper |
Conductor Diameter | 0.6 mm (22 AWG) |
Insulation Material | General PVC |
Insulation Diameter | 1.0 mm ± 0.10 mm |
Shield Type | Spiral Aluminium Foil |
Drain Wire | 0.4 mm Solid Tinned Copper (24 AWG) |
Jacket Material | Grey PVC with Rip Cord |
Outer Jacket Diameter | 5.6 mm ± 0.20 mm |
Operating Temperature | Up to 60°C |
Rated Voltage | 30 V |
Conductor DC Resistance (20°C) | < 7.31 Ω / 100 m |
Insulation Resistance (20°C) | > 200 MΩ·m |
Cable Weight (Approx.) | ~5.5 – 6.5 kg / 90m coil |
Packaging | Coil – 90 Meters |
🧪 Electrical Characteristics
Parameter | Value |
Conductor DC Resistance | < 7.31 Ω / 100 m |
Insulation Resistance | > 200 MΩ·m |
Voltage Rating | 30V |
Temperature Rating | 60°C |
Crosstalk | Negligible |
Shielding Efficiency | High (Aluminium Foil) |
📦 Packing Information
Details | Specification |
Packing Type | Coil |
Coil Length | 90 meters |
Approximate Weight | 5.5 – 6.5 kg |
Marking | Length marking with part info and batch |
🎯 Applications
- Telephone & Voice Systems
- Intercom Wiring
- Access Control
- Security & Alarm Systems
- Signal & Data Transmission (Low-Speed)
Design

🔧 PONY CABLES – Dependable Connectivity. Built to Perform.
📦 Available in 90M Coils | RoHS Compliant | Shielded for Clean Signal
