5 Pair Telephone Cable - Coil of 90 Meter

5 Pair Telephone Cable - Coil of 90 Meter

Sold by: MA Tech

Regular price PKR 23,098
Regular price Sale price PKR 23,098
Sale Sold out
Shipping calculated at checkout.

5 Pair Telephone Cable – Coil of 90 Meters


Shielded 22 AWG Solid Copper Communication Cable
Part Type: 5 Pair | F/UTP | 22 AWG | PVC Jacket | 90M Coil


📘 Product Overview

The 5 Pair Shielded Telephone Cable is engineered for high-performance voice and low-frequency signal transmission. With solid 22 AWG bare copper conductors, double shielding (Mylar + Aluminium foil), and a dedicated drain wire, this cable ensures excellent EMI protection, low crosstalk, and stable performance across diverse installations.

Its durable PVC outer jacket and rip cord enable easier handling and installation, making it ideal for use in telephony, intercom, data systems, and access control applications.


5 Pair Shielded Telephone Cable high-performance voice aur low-frequency signal transmission ke liye design ki gayi hai. Is mein solid 22 AWG bare copper conductors, double shielding (Mylar aur Aluminium foil), aur ek dedicated drain wire mojood hai, jo behtareen EMI protection, kam crosstalk, aur stable performance faraham karta hai.

Iska mazboot PVC outer jacket aur rip cord asani se handling aur installation ko mumkin banate hain, jis se yeh telephony, intercom, data systems, aur access control applications ke liye behtareen choice hai.


Key Features

  • Solid Bare Copper Conductors – 22 AWG (0.6 mm)
  • PVC Insulated Twisted Pairs
  • Double Shielded: Mylar + Aluminium Foil
  • Tinned Copper Drain Wire – 24 AWG (0.4 mm)
  • Grey PVC Jacket with Nylon Rip Cord
  • All Pairs Usable Simultaneously
  • Low Crosstalk & Stable Signal Transmission
  • Supplied in 90-Meter Coils

📊 Technical Specifications

Attribute Specification
Number of Pairs 5 (10 Conductors)
Conductor Material Solid Bare Copper
Conductor Diameter 0.6 mm (22 AWG)
Insulation Material General PVC
Insulation Diameter 1.0 mm ± 0.10 mm
Shield Type Mylar + Spiral Aluminium Foil
Drain Wire 0.4 mm Solid Tinned Copper (24 AWG)
Jacket Material Grey PVC with Rip Cord
Outer Jacket Diameter 7.3 mm ± 0.20 mm
Operating Temperature Up to 60°C
Rated Voltage 30 V
Conductor DC Resistance (20°C) < 7.31 Ω / 100 m
Insulation Resistance (20°C) > 200 MΩ·m
Approx. Cable Weight (90m) ~8.0 – 9.0 kg
Packaging Coil – 90 Meters

🧪 Electrical Characteristics

Parameter Value
Conductor DC Resistance < 7.31 Ω / 100 m
Insulation Resistance > 200 MΩ·m
Voltage Rating 30V
Temperature Rating 60°C
Crosstalk Minimal
Shielding Efficiency High (Dual Shielding)

📦 Packing Information
Details Specification
Packing Type Coil
Coil Length 90 meters
Approximate Weight 8.0 – 9.0 kg
Marking Meter-marked with part and batch number

🎯 Applications

  • Landline Telephone Wiring
  • PBX and Voice/Data Communication
  • Intercom Systems
  • Security & Alarm Systems
  • Access Control Wiring

Design


🔧 PONY CABLES – Dependable Communication Infrastructure for Every Project

📦 Ready-to-use in 90M Coils | RoHS Compliant | Dual Shielded for Signal Integrity
