Armoured 100 Pairs Telephone Cable - (0.4mm)Mtr
Armoured 100 Pairs Telephone Cable - (0.4mm)Mtr
Sold by: MA Tech
🔷 Armoured 100 Pair Telephone Cable – 0.4mm (Sold by the Meter, Drum Packaging)
📘 Product Overview
The Armoured 100 Pair Telephone Cable is a robust, high-capacity solution for demanding outdoor telecom installations. Engineered with 200 solid copper conductors, multiple layers of shielding, and grease filling, it offers exceptional protection against water ingress, rodents, and environmental stress.
Ideal for underground and duct installations, this cable ensures uninterrupted multi-line voice and analog signal transmission over long distances.
oor Telephone Cable | Jelly Filled | Armoured | LDPE Jacket
Armoured 100 Pair Telephone Cable ek mazboot aur high-capacity cable hai jo bahar ke mushkil environments mein telecom installations ke liye design ki gayi hai. Is cable mein 200 solid copper conductors, kai shielding layers, aur grease filling hoti hai jo pani ke ghusne, chuho ke nuksaan, aur environmental stress se behtareen tahaffuz deti hai.
Yeh cable underground aur duct installations ke liye ideal hai, aur lambe faslay tak multi-line voice aur analog signal transmission ko bina rukawat ke ensure karti hai.
Khaas Features:
Outdoor Telephone Cable | Jelly Filled | Armoured | LDPE Jacket
✅ Key Features
- 22 AWG (0.4 mm) Solid Bare Annealed Copper Conductors
- Core Waterblocking Jelly Filling
- PP Spiral Color Tape for Easy Pair Identification (25×4 Groups)
- Triple Shielding: Aluminium + Polyester + Corrugated Steel
- HDPE Insulation + Dual LDPE Jackets (Inner/Outer)
- High Crosstalk Immunity & Signal Integrity
- Available in 500 or 1000 Meter Drums
- Engineered for Harsh Outdoor and Underground Use
📊 Technical Specifications
| Attribute | Specification |
| Number of Pairs | 100 (200 Conductors) |
| Conductor Diameter | 0.4 mm |
| Conductor Material | Solid Bare Annealed Copper |
| Insulation Diameter | 1.0 mm |
| Insulation Material | High Density Polyethylene (HDPE) |
| Shielding (1) | Spiral PP Color Tape (Grouped 25×4 Pairs) |
| Shielding (2) | Polyester Tape Wrap |
| Shielding (3) | Spiral Aluminium Tape – 0.25 mm |
| Inner Sheath | Black LDPE – 1.4 mm |
| Armouring Layer | Corrugated Steel Tape – 0.25 mm |
| Outer Sheath | Black LDPE – 2.0 mm |
| Grease Filling | Full Waterblocking Jelly Filling |
| Packaging | Drum (500 or 1000 Meters) |
📈 Electrical Characteristics
| Property | Value |
| DC Resistance (Max) | 65.1 Ω/km |
| DC Resistance Unbalance (Max) | 5.00% |
| Insulation Resistance (500V DC) | > 3000 MΩ/km |
| Working Capacitance (800Hz) | ≤ 58 nF/km (≤ 10 Pairs), ≤ 57 nF/km (>10 Pairs) |
| Pair-to-Pair Capacitance Unbalance (800Hz/300m) | ≤ 250 pF/km |
| Electrical Strength (1 min) - Conductor to Conductor | 1 KV |
| Electrical Strength (1 min) - Conductor to Shield | 3 KV |
🎯 Applications
- Outdoor Telephone and Intercom Systems
- Underground Multi-Pair Telecom Cabling
- High-Density PBX Wiring
- Moisture and Rodent-Proof Long-Distance Signal Transmission
- Commercial/Industrial Communication Infrastructure
Design
INSULATION CHROMATOGRAM
CHARACTERISTICS
🛠️ Engineered by PONY CABLES – The Ultimate Choice for Cabling
💼 Dependable performance and durability where high-pair capacity and rugged conditions meet.
