Security & Sound, 3 Conductor 16 AWG BC, Shielded, Riser (Mtr)
Security & Sound, 3 Conductor 16 AWG BC, Shielded, Riser (Mtr)
Sold by: MA Tech
Belden 5201FE Security & Sound, 3 Conductor 16 AWG BC, Shielded, Riser
🧾 Product Description
Security & Sound Cable, 3 Conductor, 16 AWG, Bare Copper, Shielded, Riser-Rated
Belden 5201FE is a high-performance shielded security and commercial audio cable designed for indoor riser-rated installations. The cable features three 16 AWG stranded bare copper conductors, polypropylene insulation, and Beldfoil® aluminum/polyester shielding with a tinned copper drain wire, all enclosed in a durable PVC jacket with an integrated ripcord for quick stripping.
This cable is ideal for intercom, PA, sound, and audio systems where EMI protection is required. It meets UL 1666 Riser and FT4 flame rating, ensuring safety and reliability in vertical riser shafts and other building applications.
Belden 5201FE aik high-performance shielded security aur commercial audio cable hai, jo indoor riser-rated installations ke liye design ki gayi hai.
Is cable mein teen (3) 16 AWG stranded bare copper conductors, polypropylene insulation, aur Beldfoil® aluminium/polyester shield diya gaya hai jisme tinned copper drain wire bhi shamil hai. Yeh sab ek mazboot PVC jacket ke andar hotay hain, jisme integrated ripcord hoti hai taake cable ko aasani se strip kiya ja sake.
Yeh cable intercom, PA system, sound aur audio installations ke liye ideal hai, jahan EMI (electromagnetic interference) se protection zaruri ho.
Is cable ne UL 1666 Riser aur FT4 flame rating standards pass kiye hain, jo ise vertical riser shafts aur dusri building applications ke liye mehfooz aur reliable banata hai.
🔧 Technical Specifications Summary
Feature | Specification |
Part Number | 5201FE |
Category | Security & Commercial Audio Cable (Shielded) |
Conductor Count | 3 |
Conductor Size | 16 AWG (19x29 Stranded Bare Copper) |
Insulation Material | Polypropylene (PP) |
Insulation Thickness | 0.008 in |
Conductor Colors | Black, Red, White |
Shield Type | Beldfoil® (100% Coverage), Aluminum/Polyester Tape |
Drain Wire | 24 AWG Solid Tinned Copper |
Outer Jacket | PVC - Polyvinyl Chloride |
Outer Jacket Thickness | 0.017 in |
Overall Cable Diameter | 0.195 in (Nominal) |
Ripcord | Yes |
⚡ Electrical & Mechanical Properties
Parameter | Value |
Conductor DC Resistance | 4 Ohms/1000 ft |
Shield DC Resistance | 15.2 Ohms/1000 ft |
Capacitance (C–C) | 58 pF/ft |
Capacitance (C–Shield) | 104.5 pF/ft |
Current Capacity | 6.25 A per conductor @ 25°C ambient |
Voltage Rating | 300 V RMS (UL) |
Operating Temperature Range | -20°C to +75°C |
UL Temperature Rating | 75°C |
Minimum Bend Radius | 1.875 in |
Maximum Pulling Tension | 115.9 lbs |
Bulk Cable Weight | 34 lbs/1000 ft |
✅ Certifications & Environmental Compliance
Standard / Specification | Compliance |
NEC / UL Compliance | Article 800, CMR (UL 1666 Riser) |
CSA (C/UL) | CMG |
CPR Compliance | Euroclass Eca |
Flame Ratings | UL 1666 Riser, FT4 |
CE / RoHS / WEEE / UKCA | Yes |
China RoHS | GB/T 26572-2011 |
Plenum-Rated Equivalent | 6201FE |
📦 Available Configurations
Item Number | Color | Put-Up Type | Length | UPC/EAN | Footnote |
5201FE.00305 | Chrome | Reel | 305 m | — | |
5201FE 008500 | Gray | Reel | 500 ft | — | |
5201FE 0081000 | Gray | Reel | 1,000 ft | — | Footnote: C (Crate) |
5201FE 008U1000 | Gray | UnReel | 1,000 ft | — | |
5201FE 008Z1000 | Gray | ReelTuff Box | 1,000 ft | — |
