TC-C34KN Spec:I3/E/Y/C/SD/2.8mm/V4.3 Tiandy Spark, Spark-20 Dome Camera

TC-C34KN Spec:I3/E/Y/C/SD/2.8mm/V4.3 Tiandy Spark, Spark-20 Dome Camera

Sold by: MA Tech

Regular price PKR 17,876
Regular price Sale price PKR 17,876
Sale Sold out
Shipping calculated at checkout.

TC-C34KN 4MP Motorized IR Dome Camera (2.8–12mm)


SuperLite Series | Model: TC-C34KN SPEC: I3/A/E/Y/2.8-12MM/V4.2


Key Features

  • Motorized Varifocal Lens (2.8–12mm)
  • Up to 4MP (2688×1520 @ 25fps)
  • 0.02 Lux Starlight Low-Light Sensitivity
  • Smart IR with Range Up to 30m
  • S+265 / H.265 / H.264 Compression
  • 120dB WDR (Wide Dynamic Range)
  • Built-in Mic for Audio Monitoring
  • Advanced Video Analytics: Tripwire, Perimeter
  • microSD Storage up to 512GB
  • IP66 Rated, Plastic Housing
  • PoE & 12V DC Power Options
  • Operating Temp: -30°C ~ 60°C

📸 Camera Specs

Sensor 1/2.9" CMOS
Min. Illumination Color: 0.02 Lux @ F1.6 (AGC ON)

🔍 Lens

Type Motorized
Focal Length 2.8–12mm
Aperture F1.6 (Fixed)
Field of View Horizontal: 104.7°–30.3°
Vertical: 56.5°–17.2°
Diagonal: 120.9°–34.8°
Lens Mount Φ14

📏 DORI Distance (Detect, Observe, Recognize, Identify)

Wide (2.8mm) Tele (12mm)
Detect 56.0m 240.0m
Observe 22.2m 95.2m
Recognize 11.2m 48.0m
Identify 5.6m 24.0m

💡 Illumination

IR LEDs 4
IR Range Up to 30m
IR Wavelength 850nm

🎞️ Video & Audio

Max. Resolution 2688×1520 @ 25fps (4MP)
Main Stream PAL: 25fps @ 2688×1520, 2560×1440, 2304×1296, 1920×1080, 1280×720
NTSC: 24fps @ 2688×1520, 2560×1440; 30fps @ 2304×1296, 1920×1080, 1280×720
Sub Stream PAL: 25fps @ 704×576, 704×288, 640×360, 352×288
NTSC: 30fps @ 704×480, 704×240, 640×360, 352×240
Video Compression S+265 / H.265 / H.264B/M/H
Bitrate 32Kbps – 6Mbps
Audio Compression G.711A / G.711U
Audio Sample Rate 8kHz
Audio Input Built-in Mic

🖼️ Image Features

Enhancement BLC / HLC / AGC / 3D DNR / Defog
White Balance Auto, Semi-Auto, Manual, Light-specific Modes
ROI 8 Fixed Rectangular Zones
Privacy Mask 4 Black Regions
OSD Up to 48 characters or 16 Chinese characters in 1 region (font sizes: 16×16, 32×32, 48×48, 64×64)

🧠 Smart Features

Video Analytics Tripwire, Perimeter
General Alarms Motion Detection, Mask Alarm
Exception Alarms Disk Full, Disk R/W Error, IP Conflict
Linkage Methods Recording, Capture, Center Notify
Scene Behavior Rules Analyze in 1 Scene

🌐 Network

Protocols HTTP, HTTPS, TCP/IP, UDP, FTP, ICMP, DHCP, DNS, DDNS, EasyDDNS, NTP, TLS v1.2, QoS, IPv4, SSH, Unicast, RTSP
Compatibility ONVIF (Profiles S/T/G), SDK, CGI, P2P (exclusive with Profile G), Milestone
ANR Yes
Remote Connections ≤ 2
Client Software Easy7 (VMS), EasyLive Plus (Mobile)

🔌 Interface & Storage

Network Port 1 × RJ45 (10/100 Mbps)
Reset Button Yes (Internal)
Built-in RTC Yes
Local Storage microSD / SDHC / SDXC (up to 512GB)

⚙️ General

Housing Plastic (SuperLite Series)
Protection IP66, Surge: 4000V, ESD: 6000V
Operating Temp -30℃ ~ 60℃ (-22℉ ~ 140℉)
Humidity ≤ 95% RH

🌍 Language Support (19 Languages)

English, Simplified Chinese, Traditional Chinese, Spanish, Korean, Italian, Turkish, Russian, Thai, French, Polish, Dutch, Hebrew, Arabic, Vietnamese, German, Ukrainian, Portuguese, Albanian
